200027D

Technical Data Main Characteristics Polarity GND or + CUT-OFF Temperature range- 40 to +85 °C Housing material Zinc alloy Weight 500 g Protection degree (ISO20653) IP67 - IPX9K Compliant with directive reach (2006/121/ec) - elv (2000/53/ec) power circuit Continuous rating 300 A Overload 3000 A (5 s) Max DC voltage 48 V Terminals size M10 Contact resistance <20 mΩ Tightening torque 13 N.m±20% Terminals material Silver plated copper CONTROL circuit Type of handle Removable in OFF position
