202313

Technical Data Main Characteristics Rated voltage 12 / 24 V Temperature range- 40 to +85 °C Housing material PBT glass filled Housing colour Black Weight 1000 g Protection degree (ISO20653) IP42 Compliant with directive REACH - 2000/53/CE Approved according to ISO10133 power circuit Continuous rating 300 A Overload 1500 A (15 s) Max DC voltage 16 / 32 V Terminals size M10 Contact resistance <1 mΩ Terminals length 10 mm Tightening torque 14N.m±20% Terminals material Silver plated copper Control circuit Voltage range 10.5 - 16 V / 18 - 32 V Control signal Monostable Switching current 10 A - 12 V / 7.3 A - 24 V (200 ms) Idle current in OFF position 0 mA connection 6 wires cable auxiliary control Type Manual auxiliary circuit Type Status feedback (changeover relay) Continuous rating 100 mA max
